The BorgWarner Airwerks S368SX-R turbocharger with 76mm turbine (PN: 13767105020) is a high-performance solution designed for serious enthusiasts seeking to maximize reliability, efficiency and power output from your engine. This 76mm turbine variant is BW’s fastest spooling 100+ lb/min journal-bearing turbocharger.
The BorgWarner Airwerks 68mm S368SX-R (8876) turbocharger is purpose-built for high-output applications (up to 1000HP) with early spool. Whether you're considering single or twin turbo installations, competitive drag racing, or high-performance street builds pushing up to 1000 HP, the SX-R sets a new standard for efficiency, reliability, and power output within the realm of cost-effective journal-bearing turbochargers.
This turbocharger is engineered to excel with its Forged-Milled Wheel (FMW) compressor design and advanced aerodynamics. Its ability to maintain peak efficiency while spooling early and supporting a wide range of horsepower requirements makes it an optimal choice.
With the BorgWarner Airwerks 68mm S368SX-R turbocharger, you can trust in its capability to deliver consistent, reliable performance, allowing you to push the boundaries of power output without compromising on efficiency or reliability.
Features & Benefits:
- Supports up to 1000 HP
- Low rotor inertia (quicker spooling)
- 360-degree thrust bearing
- Integrated speed sensor port
- Forged milled compressor wheel
- Flexible compressor cover outlet options
- Pre-machined boost port
- Optimized compressor stage aerodynamics
COMPRESSOR SPECIFICATIONS
- Compressor Type: Forged-Milled Wheel (FMW)
- Compressor Wheel OD (exducer): 88mm
- Compressor Wheel Inducer: 68mm
- Max Flow Rate: 103 lb/min
- Max Turbo Speed: 580 m/s
- Compressor Housing Connections:
- Inlet: 4.0″ Hose Coupler
- Outlet: 2.5″ Hose Coupler
TURBINE SPECIFICATIONS
- Turbine Type: Inconel S300SX Turbine Wheel
- Turbine Wheel OD: 76mm
- Housing Material: D5S
- Housing Size and A/R ratio: S300 SXR is available in four (4) different turbine housing configurations:
- 0.88 A/R T4 Single Scroll
- 0.91 A/R T4 Twin Scroll
- 1.00 A/R T4 Twin Scroll
- 1.10 A/R T4 Twin Scroll
- Turbine Outlet: 3" Marmon OR Optional 3" V-Band
